DMX 512, master-slave and sound activated or auto operation
Setting and addressing:
DMX data In/Out:
XLR 3Pin(XLR 5pin is optional)
Light source leds:
150W High Output White LED
Optics beam angle:
Pan- tilt pan:
540° (Speed adjustable)
led moving head stage light
Packaging & Delivery
standard export package
Shipped in 5 days after payment
Dj Bar Party Lights 16 Channels Sound Activated Control 150W White Led Wash Moving Head Lighting
The Lighting Effect For Your Reference:
8 bit smooth dimming
Electronic dimmer:0-100% linear
High speed strobe effect with 1-25 flashers per second
Built-in color changing macro
Built-in color fade in & out macro
Built-in auto programs and speed adjustable
Control and programming
Control mode: DMX 512, master-slave and sound activated controllable or auto operation
Specific computer control software as optional
DMX channels: 10CH ,12CH, 14CH and 16CH optional
Setting and addressing: LCD
DMX data In/Out: XLR 3Pin(XLR 5pin is optional)
8 gobos +white, wheel rotation and shake
6 gobos +white, wheel rotation and shake
Gobos 7 colors +white, rotation with variable direction and speed
8-facet Prism, bi-directionally rotatable at variable speeds
Pan: 540° (Speed adjustable)
Tilt: 270° (Speed adjustable)
Beam angle: 15°
Flicker free(refresh rate>4K Hz)
Light output(full bright): 14020LUX@5M at White light
Electronic protection against short circuit
With safety chain throught holes at the rear
Rigging & Assembling
Power consumption: Max. 250W
Auto switching power supply unit
Power supply: AC100V-240V,50/60Hzz(auto-ranging)
Power In/Out: Blue and White Powercon
Two 1/4 turn fastening Omega Clamps
Cooling & thermal managemenal thermal
Thermal management system ensures long life of LEDs
Entire casing as heat sink for LED source
Cooling: forced air convection, with three silent fan
Cooling fan speed auto change according to temperature
when the internal temperature is up to 40° and then the
when the internal temperature is up to 40° and then the fans begin to work, when the internal temperature is up to 70° and the brightness reduce half.
Enviroment and physical
IP rating: IP20
Environment temp: -20℃-40℃
Packing size(cm): L30.5×W30.3×H50
